Product Model
FT-20X
Product Introduction
Shouguang Feitian Electronics Co., Ltd. is a high-tech enterprise specializing in the design, research and development and production of piezoelectric ceramic products. The company has a R & D team with rich experience, employs many well-known domestic experts in the piezoelectric ceramic industry, and maintains good cooperative relations with Shandong University, Tsinghua University, Chinese Academy of Sciences, Shanghai Silicate Research Institute and other units.
Product Parameters
Model | FT-20X | resonance frequency | 1Mhz±10% | Static capacitance | 550pf±20% |
resonance impedance | <150Ω | Protection level | IP68 | Working temperature | 0.1-85℃ |
Withstand voltage | ＜?2.6Mpa | emission beam angle | 5°-10° | Receiving sensitivity | ≥ 120mv (half wave) |
Shell material | polymer material | Emitting surface size | φ20mm | Operating voltage | ≥ 3v |
Sealing mode | epoxy resin potting | Lead Position | Sensor Center | Line Type | double core wire |
